24.99 Lac / Piece
| Business Type | Manufacturer, Exporter, Supplier, Trader |
| Click Here to View Catalogue |  View |
| Brand Name | Enersol Biopower® |
| Country of Origin | India |
| Click to view more | |
Preferred Buyer From
| Location | India, South Africa, Nepal, Bangladesh, Myanmar |
Product Details
Capacity
284KW (35KVA)
Auxiliary Power Required
3.5hp
Biomass Consumption per Hour
42kg/hr.
Gas flow (NM3/hr.)
84NM³/hr.
Thermal Output At 100%
105,000Kcal/hr
Thermal Output At 80%
84,000 Kcal/hr.
Specifications
| Brand Name | Enersol Biopower® |
| Capacity | 284KW (35KVA) |
| Model Name | ESB-R BIO-28 |
| Model No. | ESB-R28 |
| Fuel | 100% Biomass |
| Type of Gasifier | Downdraft Gasifier |
| Man power required | 1.2nos |
| Auxiliary power required | 3.5hp |
| Biomass consumption per hour | 42kg/hr. |
| Gas flow (NM3/hr.) | 84NM³/hr. |
| Thermal output at 100% | 105,000Kcal/hr |
| Thermal output at 80% | 84,000 Kcal/hr. |
| Gasification temperature | 1050- 1100°C |
| Average gas calorific value | ≥1000 |
| Biomass feeding system | Manual / Automatic |
| Ash removal system | Manual |
| Ash content | 5-7% |
| start up | Auto ignition |
| Acceptable moisture in biomass | less than 20% |
| Material of construction | Mild Steel, Ceremic Brick & Stainless Steel |
| Water tank capacity | 700-800ltrs. |
| Producer gas genset capacity | 28KW (35KVA) |
| Starter | 12V starter |
| Power factor | 0.8 P.F. |
| Governor | Mechanical / Electronic governor |
| Phase | Three phase |
| Amps per phase | 45amps/phase @100% 36amps/phase at 80% (three phase) |
| Frequency | 50Hz |
| Voltage | 415V |
| Engine Ignition system | Spark Ignition |
| Stroke | Four stroke engine |
| Bore x Stroke | 107 x 120 |
| Rated speed | 1500RPM |
| No of cylinder | Six cylinders |
| Lube oil sump capacity | 18ltrs. |
| Cooling system | water cooled |
| Control panel | provided |
| Battery | Exide |
| Acoustic enclosure (canopy) | yes |
| Weight | 3-3.5ton |
| Size (Gasifier) | L18 x W15 x H20 (feet) |
